# The Science Behind Crow's Nest's Burn Rate Types

In the previous post I presented Crow’s Nest’s central idea, that project burn rates aren’t constant and can be divided into certain categories. That certainly sounds plausible, but you don’t have to take my word for it, there’s actual evidence.

### Preprocessing Harvest Time Entries

So I put on my data scientist’s hat and started an investigation. I exported my Harvest data from 2018 till today and fired up Jupyter Lab. Using the pandas library, time entries can be easily be grouped by project:

``````time_entries = pd.read_csv("data/harvest_time_report_from2018-01-01to2020-09-30.csv", decimal=",", index_col=0, parse_dates=True)
only_billable = time_entries[time_entries['Billable?'] == 'Yes']
grouped_by_project = only_billable.groupby("Project")
``````

Resampling the data to an equal amount of bins and plotting it lead to the conclusion that in some long-running projects (mostly retainers that I don’t close), this grouping wasn’t as informative as I needed it to be.

``````index = 0
length = 8

for name, group in grouped_by_project:
timeSpan = group.index[-1] - group.index[0] + timedelta(days=1)
rule = math.ceil(timeSpan.days / length)
group.resample(str(rule)+"D", closed='right')['Hours'].sum().plot.bar(ax=axes[math.floor(index/4),index%4])
``````

The problem, as you can observe below, is that for long-running projects there are bound to be gaps of sometimes weeks between consecutive workloads:

So we need to split up our data into singular workloads, a sub-grouping of projects. To do this, I first resampled the data to business days (`'B'`). Next we `mask` our data-frame columns that contain no recorded hours, and are preceded or followed by another empty row. Thus, those hours entries become `NaN`, and can later be dropped and serve as split boundaries:

``````hours_each_business_day = filtered_grouped.resample('B').sum()

#              Hours
# Date
# 2018-07-20   2.51
# 2018-07-23   1.96
# 2018-07-24   3.97
# 2018-07-25   0.00
# 2018-07-26   0.93
# 2018-07-27   1.57
# 2018-07-30    NaN
# 2018-07-31    NaN
# 2018-08-01    NaN
# 2018-08-02    NaN
# 2018-08-03   4.94
# 2018-08-06   3.88
# 2018-08-07   4.88
# 2018-08-08   1.28
``````

We can now split at those breaks and drop empty and too short workloads:

``````workloads = []

breaks = hours_by_project.isnull().all(axis=1)
workloads_by_project = [group.dropna(how='all') for _, group in hours_by_project.groupby(breaks.cumsum())]
# remove empty workloads and too short ones
